Standard Machine Features
Fanuc 0i-TF Plus Control Unit
Strong and Wide Body Structure
X and Z axis Linear Roller Guide + Box Way
1.000mm Chuck diameter
Diagonal 8-degree 4-station Servo Turret
Pallet Type Chip Conveyor
Central Lubrication System
Foot Pedal for Chuck Clamp-Unclamp
Fully enclosed case
3-color warning lamp
Interior lighting lamp
Machine mounting foot set
Tool Bag and Kits
CE Equipment
Transformer
Capacity Information
Max. swing over bed: Ø1.400 (mm)
Max. turning diameter: Ø1.250 (mm)
Max. turning height: 1.000 (mm)
Chuck diameter: Ø1.000 (mm)
Worktable load capacity: 4.000 (kg)
Max. spindle speed: 5 ~ 400 (rpm)
Spindle and motor transmission type: Gearbox (Double Speed)
Spindle motor power: 22 / 30 (kW)
Spindle motor torque: 210 (Nm)
Spindle torque (Output): 8.000 (Nm)
Turret type: Servo Turret
Number of turret stations: 4 station Servo Turret with 8 degree inclination
Square tool dimensions: 40x40 (mm)
Boring bar holder diameter: Ø80 (mm)
X axis travel: -50 ~ 650 (mm)
Z axis travel: 650 (mm)
Beam lifting stroke: 700 (mm)
Guide Type / Dimensions (X*Z): 55*45 (mm) Linear Roller Guide + Box way
Ballscrew Diameter (X*Z): Ø63*63 (mm)
X*Z axis rapid feedrate: 15*12 (m/min.)
Cutting feedrate: 5 (m/min.)
X axis motor power / Torque: 3,5 (kW) / 22 (Nm)
Z axis motor power / Torque: 4,7 (kW) / 30 (Nm)
Machine dimensions (WxDxH): 3.800x2.800x3.500 (mm)
Approximate Machine weight: 13.800 (kg)
